Through the combining glass

Press release issued: 6 October 2014

Trying on clothes when a shop is closed could become a reality thanks to new research that uses semi-transparent mirrors in interactive systems and which will be unveiled at an international conference tomorrow [Tuesday 7 October].

The research paper, to be presented at one of the world’s most important conferences on human-computer interfaces - ACM UIST 2014 [5-8 October], could change the way people interact and collaborate in public spaces, such as museums and shop windows.

The research, led by Professor Sriram SubramanianDr Diego Martinez Plasencia and Florent Bethaut from the University of Bristol’s Department of Computer Science, builds on a mirror’s ability to map a reflection to one unique point behind the mirror, independently of the observer’s location.

In a museum, people in front of a cabinet would see the reflection of their fingers inside the cabinet overlapping the exact same point behind the glass. If this glass is at the front of a museum cabinet, every visitor would see the exhibits their reflection is touching and pop-up windows could show additional information about the pieces being touched.

Visitors could also interact with exhibits by focusing their eyes on them. By directly pointing at the exhibit with their reflection, instead of pointing at them through the glass, people could easily discuss the features of the exhibits with other visitors.

Combining this approach with different display technologies offers interesting possibilities for interaction systems. By placing a projector on top of the cabinet, fingertips could work as little lamps to illuminate and explore dark and sensitive objects.  When a hands reflection cuts through the object, the projections on visitors’ hands could be used to reveal the inside of the object, which would be visible to any user.

The researchers have also demonstrated artistic installations that combine this approach with volumetric displays. The musicians would record loops in their digital mixers and these appear as floating above the digital mixer. Musicians could then grab these representations, to play them or tweak them with different musical effects.

Dr Diego Martinez, a Researcher in Human-Computer Interaction in the Bristol Interaction and Graphics (BIG) group, said: “This work offers exciting interactive possibilities that could be used in many situations. Semi-transparent surfaces are everywhere around us, in every bank and shop window. One example, is when people can’t access a shop because it’s closed.  However, their reflection would be visible inside the shop window and that would enable them to try clothes on using their reflection, pay for the item using a debit/credit card and then have it delivered to their home.

“The possibility to blend together the spaces in front and behind the semi-transparent mirror could mean a whole new type of interactive experience. While projectors can only augment the surface of objects, combining them with reflections allows people to reveal what’s inside the object or even purely virtual objects floating around them.”


‘Through the combining glass’, Diego Martinez Plasencia, Florent Berthaut, Abhijit Karnik, Sriram Subramanian, Proceedings of ACM UIST 201427th ACM User Interface Software and Technology Symposium

Further information

About the Bristol Interaction and Graphics

The Bristol Interaction and Graphics (BIG), based in the University of Bristol’s Department of Computer Science, is united by a common interest in creative interdisciplinarity.  BIG acts as a hub for collaboration between social scientists, artists, scientists and engineers to combine efficient and aesthetic design. The group is particularly interested in areas which couple the design of devices with deployment and evaluation in public settings. Members of the group have expertise in research areas spanning human-computer interaction, visual and tactile perception, imaging, visualisation and computer-supported collaboration.

About the ACM Symposium on User Interface Software and Technology (UIST)

The 27th ACM UIST symposium will take place from Sunday 5 to Wednesday 8 October 2014 in Honolulu, Hawaii, USA.

The ACM Symposium on User Interface Software and Technology (UIST) is the premier forum for innovations in human-computer interfaces. Sponsored by ACM special interest groups on computer-human interaction (SIGCHI) and computer graphics (SIGGRAPH), UIST brings together people from diverse areas including graphical and web user interfaces, tangible and ubiquitous computing, virtual and augmented reality, multimedia, new input and output devices, and CSCW.
